| Model |
HA01 (Hide Away 3 LED ) |
| Product Number |
HA01 |
| LED |
High-power LED x 3pcs |
| Warning Patterns |
14 Flash Patterns |
| Operating Voltage |
12~24VDC |
| Avg. Current |
0.28A @12.8VDC / 0.15A @24VDC (varies with flash pattern) |
| Avg. Power |
3.58 Watts (varies with flash pattern) |
| Max. Current |
0.56A @12.8VDC / 0.30A @24VDC |
| Max. Power |
7.17 Watts |
| Wire-Red |
+Vcc, 20cm (22AWG) |
| Wire-Black |
-GND, 20cm (22AWG) |
| Wire-Yellow |
+Vcc for “ID & Flash pattern” selection, “Starter” set up or unlock, 20cm (22AWG) |
| Wire-Blue |
Connect all blue wires together among warning lights , 20cm (22AWG) |
| Fuse Recommended |
1A |
| Multi-Unit Synchronization |
Up to 16 units |
| Available Color |
AMBER |
| IP Level |
|
| Approval |
SAE J595 Class 1,CAL T13, ECE R65 XA1/XB1, ECE R10 |
